Wine Guardian® SS018 Ductless Split Wine Cellar Cooling Evaporator, 2,800BTUH, 115Vac, Single Phase, 60Hz
Item
99H0292-10
FEATURES
The SS018 Ductless Split wine cellar cooling unit is a cutting-edge system versatile enough for either surface-mounting or through-the-wall mounting. It is ideal for small wine cellars which have no room for mechanical equipment or are unable to accommodate ductwork. Always use the wine cellar cooling calculator to determine if the SS018 will be suitable for your wine storage application.
• Commercial-grade, corrosion-resistant construction for long-term durability• Fan-coil can be mounted through-the-wall or surface mount— exclusive to this unit
• Condensing unit operating capacities from 20°F/-7°C to 115°F/46°C with standard low ambient
• Condensing unit standard with outdoor enclosure
• Small footprint— fan coil fits well within racking or above a doorway
• Quiet and efficient operation
• Adjustable louvers
SPECIFICATIONS
Performance• Net Cooling Capacity Total/Sensible
@10°F (minus 12°C) condenser inlet air: 2870/2300 BTUH
@40°F (4°C) condenser inlet air: 2580/2050 BTUH
@60°F (15°C) condenser inlet air: 2860/2230 BTUH
@70°F (21°C) condenser inlet air: 2870/2260 BTUH
@80°F (27°C) condenser inlet air: 2800/2220 BTUH
@100°F (32°C) condenser inlet air: 2600/2100 BTUH
@115°F (46°C) condenser inlet air: 2300/1800 BTUH
@122°F (50°C) condenser inlet air: 2000/2000 BTUH
Controls
• Type: Room mounted non-programmable combination thermostat humidistat
• Temperature Accuracy/RH% Accuracy: +/- 1 Deg F +/- 10% RH
Fan-coil Section
• Fan Motor Size: 75 Rated Watts
• Rated Air Flow (free blow): 150 CFM
Electrical Requirements
• Power: 115 Volts/1 phase/60Hz
• Current Draw - Cooling mode: 0.7 Amps
Cabinet
• Fan coil construction: Aluminum
• Finish: Black - textured epoxy powder coat
• Weight (lbs.): 25
• Dimensions (inches):
Width: 14.25
Depth: 13.25
Height: 15.87
• Condensate Drain: 0.5 inches
• Agency Approval(s): ETLc
Safety Standards | |
---|---|
California Prop 65 | Yes |
Weights and Dimensions | |
---|---|
Operating Weight (lbs) | 25 | Exterior Dimensions (D) (inches) | 13.310000 | Exterior Dimensions (W) (inches) | 14.250000 | Exterior Dimensions (H) (inches) | 15.870000 | Shipping Weight (lbs) | 25.000000 |
Specification | |
---|---|
Maximum Capacity (BTU/H) | 2,800 | Minimum Capacity (BTU/H) | 400 | Model | SS018 Evaporator | Defrost Sensor | No | High Ambient Protection | No | Low Ambient Protection | No | Serving Temperature | No | Water Cooled | No |
