Legacy™ 92% AFUE Condensing Gas Furnace, Single Stage, 18 Speed ECM

Grouped product items
Product Name
Bryant Legacy™ Multipoise Furnace, 92% AFUE, Single Stage, 18 Speed ECM, 40,000 BTU, 115/1 MFR: Item: 912SE36040M14
Bryant Legacy™ Multipoise Furnace, 92% AFUE, Single Stage, 18 Speed ECM, 40,000 BTU, 115/1 MFR: Item: 912SE36040M17
Bryant Legacy™ Multipoise Furnace, 92% AFUE, Single Stage, 18 Speed ECM, 60,000 BTU, 115/1 MFR: Item: 912SE36060M14
Bryant Legacy™ Multipoise Furnace, 92% AFUE, Single Stage, 18 Speed ECM, 60,000 BTU, 115/1 MFR: Item: 912SE42060M17
Bryant Legacy™ Multipoise Furnace, 92% AFUE, Single Stage, 18 Speed ECM, 80,000 BTU, 115/1 MFR: Item: 912SE48080M17
Bryant Legacy™ Multipoise Furnace, 92% AFUE, Single Stage, 18 Speed ECM, 80,000 BTU, 115/1 MFR: Item: 912SE60080M21
Bryant Legacy™ Multipoise Furnace, 92% AFUE, Single Stage, 18 Speed ECM, 100,000 BTU, 115/1 MFR: Item: 912SE60100M21
Bryant Legacy™ Multipoise Furnace, 92% AFUE, Single Stage, 18 Speed ECM, 100,000 BTU, 115/1 MFR: Item: 912SE66100M21
Bryant Legacy™ Multipoise Furnace, 92% AFUE, Single Stage, 18 Speed ECM, 120,000 BTU, 115/1 MFR: Item: 912SE60120M24

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Details

Bryant^® delivers the perfect balance of economy and lasting efficiency with our most attractively priced 90% or better gas furnace. The model 912S reliably heats your home at up to 92.1% AFUE, and is backed by more than a century of excellence.

The 912SD Multipoise Legacy™ 92 Condensing Gas Furnace features asingle-stage gas valve and ECM blower motor. The fixed-speeds, constant torque (FCT) ECM blower motor is at the heart of the electrical efficiency provided by this furnace. With an Annual Fuel Utilization Efficiency (AFUE) of 92.1% AFUE, the Legacy™ single-stage gas furnace provides added savings over standard, non-condensing gas furnaces. This Legacy Gas Furnace features 4-way multipoise installation flexibility, and is available in nine model sizes. The 912SD can be vented for direct vent/two-pipe, ventilated combustion air, or single-pipe applications. A Bryant Legacy thermostat and Legacy Air Conditioner or Heat Pump, can be used to form a complete Legacy Series System. All sizes are design certified in Canada. All sizes are design certified for use in Manufactured Housing (Mobile Home) applications when used with factory-approved MH accessory kit.

PERFORMANCE
• Fixed-speeds, constant torque (FCT) ECM blower motor for electrically efficient operation all year long in heating, cooling and continuous fan operation.
• Single-speed inducer motor, and single-stage gas valve.
• Silicon Nitride PerfectLight™Robust Hot Surface Ignitor.
• Adjustable blower speed for heating and cooling.
• Aluminized-steel primary heat exchanger.
• Stainless-steel condensing secondary heat exchanger.
INSTALLATION FLEXIBILITY
• 4-way multipoise design for upflow, downflow or horizontal installation, with unique vent elbow for 12 different venting options, including optional venting through-the-cabinet downflow venting capability.
• Factory-configured ready for upflow applications.
• Ideal height 35” (889 mm) cabinet: short enough for taller coils, but still allows enough room for service.
• Direct-vent/sealed combustion, single-pipe venting or ventilated combustion air.
APPLICATIONS
• Approved for Twinning applications with accessory kit (42060E17, 048080E17, 060080E21, 60100E21, 60120E24 models, only).
• Approved for Manufactured Housing/Mobile Home applications with MH accessory kit.
• Convertible to propane with gas conversion accessory kit.
CERTIFICATIONS
• All sizes meet ENERGY STAR® South regional standards.
• Cabinet air leakage less than 2.0% at 1.0 in. W.C. and cabinet air leakage less than 1.4% at 0.5 in. W.C. when tested in accordance with ASHRAE standard 193.
• All sizes can be installed in California air quality management districts with a 40 ng/J NOx emissions limit.

Resources

PDS912SD-06.pdf

PDS912SE-01.pdf
