FEATURES & BENEFITS
• Solid state replacement for Ranco E-15
• Reliable thermistor-type sensor is less susceptible to breakage and easier to mount
• Replaces faulty bulb-type sensors
• Time and temperature terminate
• Test pins reduce test times by 256X
• Stable pin post construction
• Voltage: 24, 120, 240 VAC
• Frequency: 50/60 Hz
• Defrost Time: Fixed 10 minutes
• Interval Time Between Defrosts: Pin-selectable 30/45/90 min
• SPDT
• N/O: 20A
• N/C: 10A
CROSS REFERENCE
• Avion: DFT100
• Ranco: E-15 controls
Safety Standards | |
---|---|
California Prop 65 | Yes |
Weights and Dimensions | |
---|---|
Operating Weight (lbs) | 0.1 | Exterior Dimensions (D) (inches) | 2.875000 | Exterior Dimensions (W) (inches) | 3.500000 | Exterior Dimensions (H) (inches) | 1.000000 | Shipping Weight (lbs) | 0.200000 |
