Toshiba Carrier VRF
The Smart Manager is a line voltage controller mounted on the wall that enables the customer to control and monitor the operation of the VRF System by using an onsite computer.
Compatible Indoor Units
MMU2 – 4-Way Cassette
MMUM – Compact 4-Way Cassette
MMC1 – Underceiling
MMK3 – High Wall
MMDB – Concealed Duct
MMD4 – High Static Duct
MMDP – Slim Duct
40TCQ – Vertical AHU
- Display all units on one screen
- Shows basic indoor unit setting on main screen
- Advance operation and master scheduling functions are available
- Up to four concurrent web browser users can be connected simultaneously
- Up to 32 user accounts can be programmed with different levels of access (at least one user must be at administrator level)
- Energy monitoring and report creation functions available
- Advance operation and master schedules can be set on a calendar
- Additional digital I/O device available
- Thin profile controller and separate power supply unit enables easy installation
- Maximum of 128 indoor units per Smart Manager (requires 2 TCC links – 64 units on each link)
| Safety Standards | |
|---|---|
| California Prop 65 | Yes |
| Weights and Dimensions | |
|---|---|
| Operating Weight (lbs) | 3.75 | Exterior Dimensions (D) (inches) | 8.000000 | Exterior Dimensions (W) (inches) | 10.500000 | Exterior Dimensions (H) (inches) | 3.500000 | Shipping Weight (lbs) | 7.000000 |
