Danfoss Hermetic Scroll Compressor R407c, 75,545BTU, 208/230Vac, Three Phase
Item
HLP075T2LP6
FEATURES & BENEFITS
• Compressor Type: Scroll• BTU Rating: 75,545
• Refrigerant: R407c
• Screw Terminals
• Oil: PVE (Polyvinyl ether)
• Voltage: 208/230
• Three Phase
• Capacitor Rating: Not Required (Compressor is Three Phase)
• RLA: 22.4
• Hertz: 60
• Suction Line Size: 7/8"
• Suction Line Height: 11.0"
• Discharge Line Size: 1/2"
• Discharge Line Height: 16.6"
| Electrical | |
|---|---|
| Hertz | 60 | Phase | 3 | RLA | 22.4 | Voltage | 208/230 |
| Specification | |
|---|---|
| Refrigerant | R407C | Compressor Type | Scroll | Suction Line Height | 11.0" | Discharge Line Height | 16.6" | Discharge Line Size | 1/2" | Oil | PVE (Polyvinylether) |
| Safety Standards | |
|---|---|
| California Prop 65 | Yes |
| Weights and Dimensions | |
|---|---|
| Operating Weight (lbs) | 90 | Exterior Dimensions (D) (inches) | 11.000000 | Exterior Dimensions (W) (inches) | 11.000000 | Exterior Dimensions (H) (inches) | 19.000000 | Shipping Weight (lbs) | 90.000000 |
