Time Delay Relay SPST, 24Vac
Item
S1061A4575C
APPLICATIONS
For replacing the exact OEM heating control components, Supco® offers the complete line of CAMSTAT® controls.
FEATURES & BENEFITS
• SPST
• Controls high current blowers, relays and contactors
• Delay ON/OFF timing
• Input: 0.12 A at 24 VAC
• UL® Recognized
• Voltage: 24 VAC Control
• Terminal: 2 & 4: N.O. 240V, 8.0 FLA/48 LRA
• Terminal: 2 & 4: N.O. 120V, 13.8 FLA/82.8 LRA
• Time: Delay off: 60 to 90 seconds
• Time: Delay on: 30 to 50 seconds
• Switch: SPST
CROSS REFERENCE
• A-1® - FF582
| Safety Standards | |
|---|---|
| California Prop 65 | Yes |
| Weights and Dimensions | |
|---|---|
| Operating Weight (lbs) | 1 | Exterior Dimensions (D) (inches) | 1.000000 | Exterior Dimensions (W) (inches) | 2.000000 | Exterior Dimensions (H) (inches) | 2.000000 | Shipping Weight (lbs) | 1.000000 |
