The Silent+ ultra slim pumps is designed to mount discreetly, in the shadow line, below a high wall unit. The pump speed adjusts with the flow rate to provide quiet operation and optimum performance.
• Ultra quiet operation
• Low profile design allows installation above a door
• Reversible position on the left or right for installation flexibility
• Capacitance technology for soft start and variable flow rate
• 5A volt-free high level safety wires, NC/NO contacts rated @ 5A inductive @ 230V AC
SPECIFICATIONS
• Pump Type: Rotary Diaphragm
• Pump Length: 11.1" / 11.5" w/ Cover Plate
• Pump Width: 1.7" / 1.9" w/ Cover Plate
• Pump Height: 2.1" / 2.6" w/ Cover Plate
• Capacity: 12 GPH @ 0' Head / 6 GPH @ 33'
• Max BTUs: 54,000
• Max Head in Feet: 33
• Max Temperature: 104°F
• Sound Level: 19dB(A) @ 3'
• Dry Contact Rating: 5A NC
• Voltage: 100–250v
• Amperes:.18
• Watts: 2.1
• Remote Reservoir: N
• Plenum Rated: N
• Sound level and pump performance varies with voltage frequency.
