Rectorseal® Flaretite Refrigeration/Gas 45° Seal Combo Kit 3/8 in. & 5/8 in. (2 ea)

Item
97212
  • California Prop 65

FEATURES & BENEFITS

• Your Ultimate Solution for preventing leaks! Evolving higher pressure and more demanding hydraulic systems expose the metal-to-metal flare fitting which makes it very difficult to obtain a permanent leak free flared fitting joint. Flared Fitting Leaks are most commonly caused by misalignment, surface damage and vibration in the field. The entire seal is coated with a dry-to-the-touch, baked-on Loctite™ sealant. When inserted into a 45° SAE fitting, the concentric rings form multiple seals down the face of the flare, while the Loctite coating fills minor imperfections, dramatically increasing the integrity of the fitting. New ISO and NFPA standards strongly recommend seals for all fittings. The result is the Flaretite Seal is a permanent, in. Leak-Free in. connection, which exceeds the performance of today's ORFS fittings, and at significantly lower cost. Our seal maintains the low profile, versatility, and world-wide availability of flared fittings.
• Flared connections fitted with Flaretite Seals are today's answer for high integrity, in. Zero-Leak in. fittings, while complying with new international standards. This unique seal may be fitted to 45° SAE, refrigeration and gas fittings. The introduction of the Flaretite Seal eliminates the weakness in the original flare design.
• 45 degree copper stamping with Loctite coating
• Locking tabs clip seal securely on fitting
• Conical rings for multiple points of contact
• Rated for -40 degree F to 300 degree F
• Pressure rated up to 10,000 psi

INCLUDES

• 3/8 in. Flaretite Seals (QTY 2)
• 5/8 in. Flaretite Seals (QTY 2)

Safety Standards
California Prop 65 Yes
Specification
Connection Size 3/8 in., 5/8 in.
Weights and Dimensions
Operating Weight (lbs) 3
Exterior Dimensions (D) (inches) 4.000000
Exterior Dimensions (W) (inches) 4.000000
Exterior Dimensions (H) (inches) 4.000000
Shipping Weight (lbs) 3.000000
