FEATURES
• Operates from commercial thermostat and DCV sensor to provide a totally integrated control system• Mounts on M7215 Motor or ductwork
• The W7212 is used with Honeywell Series 72 actuators
• Combines minimum and DCV maximum damper position potentiometers with compressor staging relay
• Functions with solid state enthalpy or dry bulb changeover control
• Terminals included for connecting optional S963B1128 Remote Potentiometer for remote minimum damper position control
• LED indicates when free cooling is available
• LED indicates when module is in DCV mode
• LED indicates when exhaust fan contact is closed
• W7212C with additional "E" enthalpy curve
| Safety Standards | |
|---|---|
| California Prop 65 | Yes |
| Weights and Dimensions | |
|---|---|
| Operating Weight (lbs) | 0.7 | Exterior Dimensions (D) (inches) | 4.100000 | Exterior Dimensions (W) (inches) | 4.000000 | Exterior Dimensions (H) (inches) | 1.400000 | Shipping Weight (lbs) | 1.000000 |
| Warranty | |
|---|---|
| Country of Origin | China |
