Harris® B-15-3HV V-Series® Light-Duty Equal Pressure Mixer
APPLICATIONS
Model B15-3HV is an "E" equal or positive pressure mixer for light-duty brazing and welding with all fuel gases. This model has a mixer-to-tip tube thread size of 5/16" - 27. Its welding capacity is 1/2" (12.7mm) plate and it heats up to 60,000 BTU. Typical applications include metal art, maintenance, production brazing, etc. Conveniently vacuum-packed for point-of-purchase display.
FEATURES & BENEFITS
• Brass light-duty mixer
• “E” or positive pressure mixer
• For use with all fuel gases
• 5/16" - 27 mixer-to-tip tube thread size
• Thread sealants not required when used with genuine Harris mixers
• Welds up to 1/2" (12.7mm) plate; Heats up to 60,000 BTU
• Typical applications include metal art, maintenance, production brazing, etc.
• Engraved with model number for easy identification
• One year warranty
Safety Standards | |
---|---|
California Prop 65 | Yes |
Weights and Dimensions | |
---|---|
Operating Weight (lbs) | 2 | Exterior Dimensions (D) (inches) | 1.000000 | Exterior Dimensions (W) (inches) | 3.000000 | Exterior Dimensions (H) (inches) | 5.000000 | Shipping Weight (lbs) | 2.000000 |
