Belt Drive Blower Motor 2.4HP, 1725RPM, 208/230Vac, 11.0A, 60 °C
Item
HC58FK231
FACTORY AUTHORIZED PART BENEFITS
• Meets exact part design life testing for maximum reliability and durability.• Provides exact drop-in replacement.
• Meets exact design specifications for optimum system performance.
• Preserves equipment warranty.
• Maintains agency listings and safety standards.
• Design specifications are proprietary and not available to other parts manufacturers.
| Specification | |
|---|---|
| Motor Frame | 56Y | Motor HP | 2.4 | RPM | 1725 |
| Electrical | |
|---|---|
| Amps | 11 | Hertz | 60 | Voltage | 208/230 |
| Safety Standards | |
|---|---|
| California Prop 65 | Yes |
| Weights and Dimensions | |
|---|---|
| Operating Weight (lbs) | 35.55 | Exterior Dimensions (D) (inches) | 13.100000 | Exterior Dimensions (W) (inches) | 7.100000 | Exterior Dimensions (H) (inches) | 8.200000 | Shipping Weight (lbs) | 36.900000 |
| Warranty | |
|---|---|
| Country of Origin | United States | Parts Warranty | 1 Year |
