The DiversiTech® MP-4E is a 4 in. x 4 in. x 7/8 in. rubber/foam rubber anti-vibration EVA pad designed to reduce vibration and noise emanating from refrigeration and air conditioning equipment. The E.V.A. (Extreme Vibration Attenuation) pad is the latest generation of vibration dampening technology and the most effective anti-vibration pad available. Its superior performance is due to the special composite polymeric foam center, and it outperforms cork and rubber AV pads by greater than 3:1.
FEATURES & BENEFITS
• Rubber - Used as the anti-skid surface on the top and bottom of the pad. This rubber is a styrene butadiene rubber with aggressive tensile strength, and elongation characteristics suitable for the application. • EVA - Used as the core vibration dampening material. This EVA material is a polymeric foam material. It is constructed of a proprietary blend of ethyl vinyl acetate and other suitable enhancements. • Weight - 1.34 oz./in2 • The EVA Pad is suitable for storage and operation in a wide range of temperatures from -13°F to 167°F. • The EVA pad is highly resistant to water absorption. Additionally, the material is resistant to acid, alkali, gasoline, oil, aromatic hydrocarbons, ketones, oxidation and ozone. • Given a uniformly applied static load the following chart defines measured deflection. A loading maximum of 340 kPa (49.3 psi) is permissible with the EVA product.
