Copeland Hermetic Scroll Compressor R410A, 58,000BTU, 460Vac, Three Phase
Item
ZP57K3E-TFD-930
FEATURES & BENEFITS
• Compressor Type: Scroll• BTU Rating: 58,000
• Refrigerant: R410A
• Screw Terminals
• Oil: POE (Polyester)
• Voltage: 460Vac
• Three Phase
• Capacitor Rating: Not Required (Compressor is Three Phase)
• RLA: 10.7
• Hertz: 60
• Suction Line Size: 7/8"
• Suction Line Height: 11.73"
• Discharge Line Size: 1/2"
• Discharge Line Height: 16.17"
| Electrical | |
|---|---|
| Hertz | 60 | Phase | 3 | RLA | 10.7 | Voltage | 460 |
| Specification | |
|---|---|
| Refrigerant | R-410A | Compressor Type | Scroll | BTU Rating | 56 to 60kBTU | Suction Line Height | 11.73" | Discharge Line Height | 16.17" | Discharge Line Size | 1/2" | Oil | POE (Polyester) |
| Safety Standards | |
|---|---|
| California Prop 65 | Yes |
| Weights and Dimensions | |
|---|---|
| Operating Weight (lbs) | 85 | Exterior Dimensions (D) (inches) | 15.000000 | Exterior Dimensions (W) (inches) | 20.000000 | Exterior Dimensions (H) (inches) | 14.000000 | Shipping Weight (lbs) | 85.000000 |
