APC Control with Strobe & Sounder, Clear Lens, Red Double Gang Plate

FEATURES

The MSR-50RKAV/R/C remote accessories are designed for use with Air Products and Controls duct smoke detectors to provide the range of functionality required by your local commercial Application. Key test station in a red double gang Decora style control assembly with enhanced sounder and strobe with a clear strobe lens.

Brand Information
The MSR-50R Series remote accessories are designed for use with Air Products and Controls duct smoke detectors to provide the range of functionality required by your local commercial application.

Brand Features
The MSR-50R Series comes in two models of the controller: the MSR-50RM which provides a hidden magnet test switch and a pushbutton reset; the MSR-50RK provides a key-operated detector test and reset function. Both versions of the MSR-50R accessory are available as either a single gang remote indicator/control, or with the addition of a single gang strobe only or enhanced sounder / LED strobe assembly. As controller-only or with the added strobe only or sounder / strobe, all configurations are compatible with standard Decora style cover plates (choice of white, red or stainless steel).
The MSR-50R Series indicator/control assemblies provide:

• Tri-color visual indication of detector Pilot, Trouble and Alarm conditions

• Lever-operated quick-connect “No-Tools” four-position terminal block

• Port for plugging in the optional strobe assembly

• Key-operated detector Test and Reset functions (MSR-50RK model only)

• Magnet-operated detector Test function (MSR-50RM model only)

• Pushbutton-operated detector reset function (MSR-50RM model only)

For convenience, blue “SMOKE” and red “FIRE” strobe lens decals are included for both horizontal and vertical mounting.

Application
The strobe and audible buzzer features are not ADA compliant, and not intended for life safety notification or evacuation purposes (public mode). These functions are for duct smoke detector status indication only (private mode).

Product Information
The MSR-50RKAV/R/C remote accessories are designed for use with Air Products and Controls duct smoke detectors to provide the range of functionality required by your local commercial application. Key test station in a red double gang Decora style control assembly with enhanced sounder and strobe with a clear strobe lens.

Key Features
The MSR-50RK provides a key-operated detector test and reset function.
Enhanced sounder / LED strobe assembly.
Clear strobe lens
Decora style cover plates (red).
The MSR-50R Series indicator/control assemblies provide:
Tri-color visual indication of detector Pilot, Trouble and Alarm conditions
Lever-operated quick-connect “No-Tools” four-position terminal block
Port for plugging in the optional strobe assembly
For convenience, blue “SMOKE” and red “FIRE” strobe lens decals are included for both horizontal and vertical mounting.

Key Benefits
Designed and Manufactured in the USA.

General
Warranty 3 year

Performance
Operating Element Key switch

Electrical
Status Indicator – Alarm Red
Status Indicator – Fault Off

Environmental
Operating Temperature (Min) 0°C
Operating Temperature (Max) 49°C
Operating Temperature 0 to 49°C
Conformance
Standards UL 268

Mechanical
Weight 1lbs
Color Red
Product Height (Wo/Base) 114.3mm
Product Width 114.3mm
Key Type Remote Test station test & reset key
Housing Type Face plate
