Totaline® Perfect-Platform Media Air Cleaner 20" x 25", (MERV 11)

FEATURES

The Totaline® Perfect-Platform Series Media Air Cleaner from Totaline® offers the most well-built, sleek designed and easiest to use galvanized sheet metal filter housings on the market, for residential and light commercial use. The space saving design for vertical installations, keeps furnace off the floor allowing a cleaner, more professional installation. The platform helps eliminates the possibility of dust, pet hair, insects, rodents, water or sewer backup from entering the furnace. The platform also allows the filter to work at maximum efficiency by eliminating the need for transitions, deflectors or turning vanes, thereby saving installation time and costs.

• High efficiency MERV 11 Media Filter is an extra deep, 5-1/4 inch, 24 pleat filter which contains more media material than other filters on the market. More surface area means more collection area, longer filter life and lower static pressure. Filter lasts up to one year.
• Two, pull-out doors with handles allow filter access from both sides.
• Adjustable inlet duct opening replaces need for field forming transition, significantly reducing installation time.
• Heavy 22 gauge galvanized sheet metal has been die cut for smooth edges, allowing for a smoother installation.
• Individually boxed for convenient shipping and warehousing.
• Limited Lifetime Warranty.

SPECIFICATIONS

• Pressure Drop
.069(in./wg)@246fpm
.207(in./wg)@492fpm
• Filter Size: 20” x 25”
• Replacement Filter: P102-2025
