Bryant Legacy Multipoise Furnace, 90% AFUE, Single-Stage, Fixed Speed, Ultra Low Nox (SCAQMD Compliant), 115/1

Grouped product items
Product Name
No options of this product are available.

<p>The 935SA Legacyt 95 Ultra--Low NOx gas furnace delivers<br />consumer comfort in a unit that meets California&rsquo;s South Coast Air<br />Quality Management District (SCAQMD) and San Joaquin Valley<br />Air pollution Control District (SJVAPCD) NOx emissions limit of<br />14ng/J. Offering the performance and benefits of our Legacy Line<br />gas furnaces, this furnace releases 65% less nitrogen oxides (NOx)<br />than previous models. NOx contributes to the formation of smog<br />and acid rain and the deterioration of water quality. Lower NOx<br />emissions mean lower production of particulate matter and cleaner<br />air for the environment. Energy efficiency is at the heart of this<br />furnace with up to 95.0% AFUE gas efficiency and the<br />electrically--efficient fixed--speeds, constant torque (FCT) ECM<br />blower motor. This gas furnace also features Upflow/Horizontal<br />installation flexibility, and is available in two model sizes. All sizes<br />can be vented for direct vent/two-pipe, ventilated combustion air,<br />or single-pipe applications.</p>
<p>PERFORMANCE<br />S Ultra Low NOx -- meets the nitrogen oxides (NOx) emission<br />limit of 14 nanograms/joule for the South Coast Air Quality<br />Management Districts and San Joaquin Valley Air Pollution<br />Control District in California<br />S Fixed--speeds, constant torque (FCT) ECM blower motor for<br />electrically efficient operation all year long in heating, cooling<br />and continuous fan operation<br />S Singles--stage gas valve with pre--mix burner<br />S Pilot free, hot surface ignition<br />S Variable--speed inducer motor for consistent operation<br />S High temperature limit control designed to prevent overheating<br />S Adjustable blower speed for heating and cooling<br />S Stainless--steel primary heat exchanger<br />S Stainless--steel condensing secondary heat exchanger<br />S Cabinet air leakage less than 2.0% at 1.0 in. W.C. and cabinet air<br />leakage less than 1.4% at 0.5 in. W.C. when tested in accordance<br />with ASHRAE Standard 193<br />INSTALLATION FLEXIBILITY<br />S Upflow/Horizontal design for upflow, horizontal right or<br />horizontal left installation, with rotating vent elbow for exhaust<br />venting flexibility<br />S Factory--configured ready for upflow applications.<br />S Ideal height 35&rdquo; (889 mm) cabinet: short enough for taller coils,<br />but still allows enough room for service.<br />S Two--pipe venting, single--pipe venting or ventilated combustion<br />air.<br />APPLICATIONS<br />S Factory--configured for Natural Gas; not convertible to Liquid<br />Propane.<br />S Not approved for downflow installation<br />S Approved for installations up to 5,000 ft.</p>
